Classification:
DnV +1A1,Ice-C E0, SF, Dynpos AUTR,COMF-V (rating 3) DK (+), Supply vessel, Oil Rec,H1(P), NAUT OSV A. CLEAN DESIGN
OPTION
DEICE-C, Fi-Fi 1, Stand -by (S)
Main dimensions:
Lenght o.a.: 88,30m
Lenght b.p.p.: 77,70m
Breadth mld.: 20,00m
Depth 1st dk.: 8,60m
Depth 2nd dk : 5,40m
Draught, max. SWL: 7,00m
DWT at SWL freeboard: appr.: 4500T
Gross Tonnage : ~4486T
Net Tonnage : appr.:~1346T
Machinery / D/E-Propulsion:
Genset. outp. : 4 x Cat 3516C, each 2188bkW -Tot.: 8750 bkW
Main az.thrstrs : 2 x 2200 kW AZP 100CP
(pitch propeller)
Fwd. az.thrstr. : 1 x 880kW UL 1201 CP
Bow thruster : 2 x 1200kW TT2400 DPN CP
Emergency gen.: 1 x Cat 3406TA, Rated :345bkW
|
Certificates:
World Wide
1966 Loadline Conv, SOLAS, MARPOL,
NOFO 2005 Capasity:1820m³
Capacities:
Work/Cargo Deck area: 970 m2
Deck strength : 10 t/m2
Fresh Water : 1070m3
Fuel Oil : 953 m3
Lub oil : 29 m3
Hydraulic oil : 5 m3
Grey water : 34 m3
Bilige tank : 11 m3
Hot water tank : 45 m3
Liquid mud : 697 m3
Mud slop : 1x70 m3
Brine : 541 m3
Sludge : 11+0,8 m3
Drill water/
Water ballast : 2532 m3
Methanol : 151 m3
Special Products : 152 m3
Base oil : 206 m3
Sewage tank : 40 m3
Dry bulk : 427 m3
Waste oil : 2x10 m3
Urea : 33 m3
Navigation:
Dynamic positioning system
Type RR DP2
Speed:
Max speed: 15.5 knots
Accommodation:
The Vessel have accommodation and certificate for totally sixty-four (64) persons and one (1) hospital.
|
