Classification
DnV +1A1,Ice-C E0, SF, Dynpos AUTR, COMF-V (3), LFL*,CLEAN DESIGN
OPTION
DEICE-C, Fi-Fi 1, Stand -by (S)
Flag
Norwegian
Main dimensions:
Lenght o.a.: 85,00m
Lenght b.p.p.: 77,70m
Breadth mld.: 20,00m
Depth 1st dk.: 8,60m
Depth 2nd dk.: 5,40m
Draught, max. SWL: 7,20m
DWT at SWL freeboard: appr.: 5320T
Gross Tonnage ~4486T
Net Tonnage : appr.:~1346T
Deck load ,VCG 1m a.dk.: appr.: 3020 T
Machinery / D/E-Propulsion:
Genset. outp. : 4 x Cat 3516BTA, each 1825ekW -Tot.:7300ekW
Main az.thrstrs : 2 x 2450 kW (El. Driven R-R FP AZP100).
Fwd. az.thrstr. : 1 x 880 kW (El. Driven R-R FP)
Bow thruster : 2 x 1000 kW
Emergency gen. 1 x 320 ekW
|
Capacities:
Work/Cargo Deck area: 1005 m2
Deck strength: 10 t/m2
Fresh Water: 1000m3
Fuel Oil : 950 m3
Liquid mud: 700 m3
Slop: 190m3
Brine: 430 m3
ORO: 1820 m3
Drill water/ Water ballast:2500 m3
Methanol : 150 m3
Special Products : 150 m3
Base oil : 210 m3
Cement: 400 m3
Navigation:
Dynamic positioning
Kongsberg Simrad SDP-21
Speed
Max speed: 15,8 knots
Accommodation:
Total: 50 persons
Cabins: 10 x 1 (single) bed cabins
Cabins: 20 x 2 (double) bed cabins
Hospital: 1 off + ward 2 beds
Mess / dayroom : for 24 / 18 persons
Dayroom smokers: 10 persons
Coffee shop: 1 off, main deck
Reception: 1 off, main deck
Wardrobe : 1 off, main deck w/22 lockers.
Deck office : 1 off, C. deck
|
